Raj Process is a leading HT (High Tension) panels manufacturer in India, offering highquality, compact outdoortype systems widely used across industries. HT panels are equipped with circuit breakers or switch fuses to protect equipment from sudden voltage fluctuations, ensuring safe and reliable power distribution. Reliable Construction Fabricated using premium materials, Raj Process HT panels deliver long functional life, durability, and effective performance. Panels are manufactured with ingress protection ranging from IP42 to IP67, available in both flameproof and nonflameproof variants. Carbon steel panels are powdercoated using a seventank process for enhanced durability and finish. Customization Raj Process offers HT panels tailored to meet the specific requirements of different industries. Constructed with highgrade components, these panels ensure energyefficient, safe, and uninterrupted power supply for industrial applications. Applications Process automation and control Steel plants Sugar plants Cement plants Dairy plants Vegetable oil refineries Packaging industry Textile industries Paper industries Distilleries Powder plants Factory automation Sand plants Material handling systems Features Fully automatic system for smooth and easy operation Sterile construction to maintain hygiene standards Energyefficient design PLCcontrolled SCADA operation for advanced monitoring Compact design with optimal space utilization Carefully selected materials of construction for durability Complete sanitary design with CIP (CleaninPlace) system

Raj Process provides superior quality LT (Low Tension) Panels designed for optimal power usage and reliable industrial power distribution. Built to withstand demanding environments, our panels are fully impervious to dust and rodents, ensuring safe and uninterrupted operations. Available in drawout or fixed type executions, Raj Process LT panels are engineered to meet highperformance requirements across industries. Technical Specifications Power Control Centers: Up to 4000A rating Operating Voltage: Up to 415V in threephase, fourwire distribution systems Insulation Voltage: Up to 660V at 40°C ambient temperature ShortCircuit Withstand Capacity: 50 kA (typetested) Switchboards: Single front design with fixed or semidrawout configurations Ingress Protection: Ranging from IP42 to IP67 (flameproof and nonflameproof versions) Material Options: Carbon steel (powdercoated via seventank process) or stainless steel (finished to 420 grit) Applications Pharmaceutical industry Food processing Chemical industry Fertilizers Ceramic industry Minerals Biochemicals Cement industry Features Sturdy construction for durability Safe and reliable operation High performance under demanding conditions Corrosion resistance for long service life Low maintenance requirements

Raj Process is a leading manufacturer of A.C. & D.C. drive control panels, engineered to deliver efficient control and smooth operation of industrial machinery. Designed with advanced technology, our panels ensure reliable performance, energy savings, and longterm durability across diverse applications. D.C. Drive Panels Raj Process D.C. drive panels are ideal for powerintensive applications such as power plants, refineries, steel mills, and sugar mills. Power ratings: 7.5 KW to 750 KW Energy savings: Up to 30% Reliable control over D.C. motors for constant speed operation Smooth and consistent performance under demanding conditions A.C. Drive Panels Our A.C. drive panels efficiently regulate motor speed, making them suitable for: Pumps Fans Conveyors Mixers Mechanical equipment requiring precise speed control Raj Process designs these panels with highperformance motor control systems, converting electrical energy into mechanical output to meet diverse industrial requirements. Applications Heavy machinery Automotive industry Electronics and telecommunications Operations requiring high accuracy of movement Processes demanding maximum stability in motor RPM/speed Features Shockproof design for safety Sturdy construction for durability Compact design with polished finish Speed control or constant speed operation Reliable performance with low maintenance

Raj Process is one of the leading instruments and control panel manufacturers in India, delivering reliable and customized solutions for industrial automation and process monitoring. Our panels are manufactured as per international standards, with ingress protection ranging from IP42 to IP67, ensuring durability and safety in demanding environments. Instruments & Control Panel Manufacturer in India We manufacture both flameproof and nonflameproof panels, constructed from carbon steel or stainless steel. Stainless steel panels are finished up to 420 grit, while carbon steel panels are powdercoated using a seventank process for longlasting protection. Raj Process instruments are designed to provide accurate monitoring and control of parameters such as temperature, pressure, flow rate, and level. Our control panels are highly reliable, easy to operate, and ideal for a wide range of industrial applications. Product Range Temperature controllers Sequential timers VFD (Variable Frequency Drive) panels By integrating advanced technology and sophisticated control systems, Raj Process enhances operational efficiency, safety, and automation across industries. Precise monitoring and adjustment of parameters ensure optimized performance and quality control. Applications Pharmaceutical industry Food & beverages Chemical industry Cement industry Ceramic industry Fertilizers Minerals Biochemicals Features Simple operation Sturdy construction Safe and reliable Low maintenance Durable design Withstands extreme weather conditions

A Programmable Logic Controller (PLC) is a vital component for automating electromechanical processes. Raj Process is a leading manufacturer of PLC panels in India, delivering advanced automation solutions designed for multiple input/output arrangements, extended temperature ranges, electrical noise immunity, and resistance to vibration and impact. PLC Panels Manufacturer in India Raj Process manufactures and supplies a wide range of PLC panels using advanced technology and highquality raw materials, ensuring longlasting performance and smooth operations. We also provide customized PLC panels tailored to client requirements. Our PLC panels are widely used for automation in industries such as refineries, food, pharmaceuticals, cement, and more. Depending on client needs, we recommend globally recognized brands like Siemens and Allen Bradley. Raj Process offers both flameproof and nonflameproof PLC panels, manufactured in stainless steel or carbon steel. Stainless steel panels are finished up to 420 grit, while carbon steel panels are powdercoated via a seventank process. We also provide innovative solutions in industrial automation using PLCs, SCADA, and AC/DC drives for industries including automobile, sugar, cement, paper, chemicals, material handling, pharmaceuticals, steel, packaging, machine tools, synthetic fibers, and textiles. Applications Manufacturing units Plant automation Machine automation Commissioning of plants Pumping systems System automation Features Simple operation Sturdy construction High performance Low maintenance Durable design Withstands extreme weather conditions Safe and reliable

Raj Process is a leading MCC (Motor Control Center) panels manufacturer in India, delivering reliable and efficient solutions for centralized motor control in industrial environments. MCC panels are assemblies of enclosed sections connected by a common power bus, housing multiple motor control units such as starters, circuit breakers, and control devices. Designed to provide the appropriate quantity of power to different sections while ensuring system protection, Raj Process MCC panels are engineered for safe, efficient, and longlasting performance. MCC Panels Manufacturer in India Raj Process MCC panels are widely used in refineries, chemicals, pharmaceuticals, food & beverages, and other sectors. They are available in single and double front designs, with operational current up to 1600 A at 40°C ambient temperature and shortcircuit withstand capacity of 50 kA. Our panels support a wide range of starters, including: Automatic Star Delta Direct OnLine Soft Starters Variable Frequency Drives (VFDs) Stator Rotor Starters Autotransformer Starters Raj Process MCC panels are manufactured with ingress protection ranging from IP42 to IP67, in both flameproof and nonflameproof variants. Options include carbon steel (powdercoated via seventank process) or stainless steel (finished to 420 grit), available in single or double front fixed type. MCC Panels are Equipped With Feeder circuit breaker AC variable frequency drives PLC compatibility for automation Temperature indicators Sturdy structure with low maintenance Digital control systems Safety fuses and inbuilt overload protection Cabinets available in various materials of construction Simple operation with high performance Applications Water pumps Heavy machinery Industrial equipment Medical & office equipment Automotive industry Processing units Electronics and telecommunications

Raj Boilers, a division of Raj Process, is a prominent name in the industry, recognized for cuttingedge technology and advanced engineering solutions. We specialize in package boilers with smoke tubes, threepass design, and wetback construction, ensuring maximum heat transfer and operational efficiency. Our package boilers are equipped with advanced features such as automated controls, safety interlocks, and efficient combustion systems. Designed to meet the highest quality standards, they deliver optimal performance, reliability, and ease of operation. With a strong focus on sustainability and energy efficiency, Raj Process provides costeffective solutions tailored to client requirements. We also undertake turnkey cogeneration power plants up to 10 MW capacity, offering complete solutions from design to commissioning. Capacity 1.0 TPH to 15 TPH Steam Pressure 10.5 kg/cm² (g) to 17.5 kg/cm² (g) Fuel Fired Compatible with multiple fuels, including liquid and gas options Features Sturdy construction for longterm durability Almost zero refractory boilers for reduced maintenance Easy access for maintenance and tube cleaning Highly efficient boilers with imported burners and intelligent burner management systems for liquid and gas fuel firing Proper provision for expansion to avoid undue stresses in the boiler Highefficiency boilers equipped with economizer/air preheater Manual or automatic fuel feeding systems as per requirement Furnace with primary and secondary air systems to create turbulence and ensure complete combustion Zero leakage of flue gases due to membrane wall construction

Raj Process offers advanced thermic fluid heaters and hot water boilers designed for diverse process heat transfer applications. Our product range covers heat outputs from 0.1 million K.Cal/Hr to 6.0 million K.Cal/Hr, ensuring scalable solutions for industries with varying energy demands. Thermic Fluid Heaters Raj Process thermic fluid heaters are engineered for high efficiency and reliability, delivering precise and consistent heating for industrial processes. By maximizing energy output while minimizing fuel consumption, these heaters provide significant cost savings and operational efficiency. Hot Water Boilers Our hot water boilers are designed to deliver hot water at controlled temperatures, making them ideal for: Building heating systems Domestic hot water generation Industrial process heating Raj Process also manufactures fired boilers for the steel industry, as well as boilers for lean gas and blast furnace gas. Depending on client requirements, these boilers can be installed as fielderected units or package units, with options for onedrum or twodrum designs. Key Features High efficiency for reduced fuel consumption and cost savings Durable construction using highquality materials Reliable performance under demanding industrial conditions Customengineered designs tailored to client requirements Longterm durability with minimal maintenance needs Applications Chemical industries Pharmaceutical industries Food processing Distilleries Petrochemical plants General manufacturing

Raj Process specializes in manufacturing waste heat recovery boilers and highcapacity captive plant boilers designed to efficiently convert water into steam for power generation. These boilers are engineered to handle waste gases from industries such as oil & gas, minerals, ferrous and nonferrous metals, glass, cement, and more. Our custommade boilers are capable of generating both steam and power, making them a reliable solution for industries seeking energy efficiency and cost savings. Raj Process also offers specialized boilers for blast furnace gas, lean gas, and fired boilers for the steel industry. Whether package type or fielderected, our boilers can be customized to meet specific client requirements. Captive Plant High Capacity Boilers One of the key advantages of Raj Process captive plant boilers is their costeffectiveness. Designed with advanced technology, these boilers ensure consistent power supply while meeting the energy demands of large industrial plants. We offer Single Drum and BiDrum designs with membrane wall construction, horizontal drainable type superheaters, and vertical coil type convective superheaters. These boilers are capable of firing multiple fuels, including: LDO (Light Diesel Oil) FO (Furnace Oil) HSD (HighSpeed Diesel) LSHS (Low Sulphur Heavy Stock) Natural Gas LPG Features Fully automatic DCSoperated drum level and combustion control system requiring minimal operating staff Fast response to load variations Topsupported boiler with expansion allowed at the bottom Effectively sealed construction with minimal refractory, reducing maintenance needs Pneumatic or mechanical fuel spreading for efficient combustion Primary and secondary air systems ensure proper turbulence and suspension burning of fuel

Raj Process is a leading manufacturer and supplier of boilers and heaters in India, offering a wide range of highquality products for industrial applications. Known for robust construction, efficiency, and ease of operation, Raj Boilers are trusted across industries for reliable heating solutions. Boilers Our extensive range of IBR and nonIBR boilers are designed to burn a variety of fuels, including: LDO (Light Diesel Oil) FO (Furnace Oil) HSD (HighSpeed Diesel) LSHS (Low Sulphur Heavy Stock) Natural Gas LPG These boilers are engineered to deliver efficient heating while ensuring compliance with industry standards, making them suitable for diverse industrial processes. Heaters In addition to boilers, Raj Process manufactures heaters designed for heating liquids and gases in industrial operations. Built with advanced manufacturing techniques, our heaters provide consistent performance, energy efficiency, and durability. Key Features Robust and efficient design for longterm reliability Wide fuel compatibility for flexible operations Easy to operate and maintain Customizable to meet specific client requirements Engineered for superior energy efficiency and cost savings Applications Raj Process boilers and heaters are widely used across industries such as: Food processing Chemicals Pharmaceuticals Petrochemicals Distilleries General manufacturing.

A silo is a specialized structure for storing bulk materials such as grain, coal, cement, carbon black, wood chips, and food products. Storage silos are essential equipment in manufacturing, agriculture, mining, and food processing industries. Raj Process is a leading manufacturer of storage silos in India, offering durable and efficient designs tailored to meet the specific needs of diverse industries. Built with highquality materials and advanced manufacturing techniques, our silos are engineered to withstand harsh industrial environments while ensuring product safety and quality. Storage Silo Solutions Raj Process silos are designed to prevent contamination and maintain product integrity. With expertise in spray drying and powder handling, we also provide advanced egg powder production plants capable of drying whole egg, yolk, and albumen. To ensure optimal product quality, separate dryers are recommended for each product type. Typical Applications Foodstuffs and flour silos Chemical silos Coal silos Cement and fly ash silos Grain silos Ceramic powder silos Features Available in bolted, smoothwall, and welded designs Material options: epoxycoated carbon steel, stainless steel, carbon steel with stainless steel cladding, carbon steel with FRP coating Designed for durability and safe operation under demanding conditions Customizable to integrate seamlessly into existing process setups

Raj Process is a leading coded vessel manufacturer in India, specializing in the fabrication of carbon steel and stainless steel pressure vessels in strict compliance with ASME codes. These vessels are essential components in industrial applications, designed to safely hold gases or liquids at high pressures. Our coded vessels are widely used across processing industries due to their reliable, durable, and customized designs. Leveraging technical innovation and industry expertise, Raj Process manufactures pressure vessels tailored to meet the specific requirements of chemical, oil & gas, pharmaceutical, and other sectors. Vessel Design While coded vessels can theoretically be of almost any shape, sections of spheres, cylinders, and cones are most commonly employed. Raj Process engineers carefully design and manufacture vessels to withstand extreme conditions of temperature and pressure, ensuring safe and reliable operation for highpressure fluids. Applications Pharmaceutical industry Chemical industry Process engineering Offshore activities Petrochemical industry Food processing industry Refineries Distillery Plant Solutions In addition to pressure vessels, Raj Process is also a leading distillery plant manufacturer in India, known for quality manufacturing and innovative techniques. We provide a comprehensive range of efficient and durable distillation equipment to meet diverse industrial needs. Benefits of Distillery Process Equipment Vital for sectors such as agriculture, petroleum, and chemicals Products generate significant income through excise and taxes High demand ensures quick profitability Full support for plant installation and maintenance Complete project reports prepared for advantage assessment GrainBased Distillery Manufacturing, Raj Process manufactures advanced equipment for grainbased distilleries used in alcohol production. Grains such as wheat, barley, malt, rice, and maize are processed to produce whiskey, beer, gin, vodka, and more. Alcohol from grainbased distilleries is a key raw material for industries including medicine, chemistry, and liquor.
