Membrane separation is one
of the most widely adopted technologies for upgrading raw biogas
to high purity biomethane due to its high methane recovery,
compact footprint, modular design, low energy consumption, and
minimal chemical usage. The process employs advanced polymeric
gas separation membranes that selectively permeate carbon
dioxide (CO₂), water vapor, oxygen, and other trace gases
while preferentially retaining methane (CH₄),
producing biomethane with 96–99% methane purity. To
ensure optimum membrane performance and service life, the feed
gas is pre-treated to remove hydrogen sulphide (H₂S), moisture,
oil aerosols, and particulate matter, preventing
membrane fouling, chemical degradation, and loss of separation
efficiency. The modular nature of membrane technology also
enables easy capacity expansion, rapid installation, and
automated operation, making it a preferred solution for both
medium- and large-scale Bio-CBG plants.
In a 2-stage
membrane system, the permeate from the first membrane stage
undergoes further separation in a second stage to recover
residual methane from the CO₂-rich stream. This configuration
typically achieves 96–98% methane purity with 96–98%
methane recovery, making it an economical and
reliable solution for small- to medium-capacity Bio-CBG
plants (up to approximately 500 Nm³/h). The system
offers lower capital investment, reduced compression requirements, simpler
operation, and lower control complexity while maintaining
good product gas quality.
A 3-stage
membrane system incorporates an additional membrane stage
to recover residual methane from the second-stage
permeate stream. This configuration significantly reduces
methane slip, increasing overall methane recovery to 99% or
higher while maintaining biomethane purity above 98–99%.
Although the third stage requires additional membrane area,
compression power, instrumentation, and control complexity, it
substantially improves overall gas utilization, minimizes methane losses,
and enhances process efficiency, particularly for
large-scale commercial installations.
For small- to
medium-scale Bio-CBG plants, a 2-stage membrane system generally
provides the optimum balance between capital investment,
operating simplicity, energy consumption, and product gas quality.
For large commercial Bio-CBG projects (typically above 500–1000
Nm³/h) or applications where maximum methane recovery, reduced emissions,
and lifecycle economics are critical, a 3-stage
membrane system is often the preferred solution due to
its superior recovery performance and lower methane losses.
